M8 x 60mm part-threaded hex bolt in A4 stainless steel, manufactured to DIN 931 at property class A4-70. The plain shank reduces stress concentration at the thread run-out, suited to shear-loaded joints and structural through-bolting. A4 (316) marine grade gives outstanding resistance to saltwater and chloride corrosion - the right choice for coastal, marine, and pool environments. Free next-day UK delivery on orders over £50.
  • M8 x 60mm hex bolt marine grade 316 DIN 931 - partial thread
  • DIN 931 hex bolt M8 x 60mm A4-70 A4 marine grade stainless steel, side profile
  • Hexagon head detail - M8 x 60mm A4 stainless bolt, partial thread DIN 931
  • Simfix product label - 931A40806070PK10-SIM
  • Simfix product label - 4014A40806070PK50-SIM
M8 x 60mm hex bolt marine grade 316 DIN 931 - partial thread
DIN 931 hex bolt M8 x 60mm A4-70 A4 marine grade stainless steel, side profile
Hexagon head detail - M8 x 60mm A4 stainless bolt, partial thread DIN 931
Simfix product label - 931A40806070PK10-SIM
Simfix product label - 4014A40806070PK50-SIM

Simfix

Hexagon Head Bolt DIN 931 A4-70 A4 Stainless Steel (M8 X 60)

SKU 931A40806070PK10-SIM
£9.77
Pack size:
Free next-day delivery over £50 Next-day delivery is free when your order is over £50, or £3.95 below that threshold.
Same-day shipping before 4pm Orders placed before 4pm Monday-Friday are typically dispatched the same working day.
Secure SSL checkout Checkout is encrypted and supports secure Shopify payment options.
Speedy refunds If something is not right, contact us within 30 days of delivery and we will sort a refund or replacement quickly.

M8 x 60mm part-threaded hex bolt in A4 stainless steel, manufactured to DIN 931 at property class A4-70. The plain shank reduces stress concentration at the thread run-out, suited to shear-loaded joints and structural through-bolting. A4 (316) marine grade gives outstanding resistance to saltwater and chloride corrosion - the right choice for coastal, marine, and pool environments. Free next-day UK delivery on orders over £50.
£9.77
M8 x 60mm hex bolt marine grade 316 DIN 931 - partial thread DIN 931 hex bolt M8 x 60mm A4-70 A4 marine grade stainless steel, side profile Hexagon head detail - M8 x 60mm A4 stainless bolt, partial thread DIN 931 Simfix product label - 931A40806070PK10-SIM Simfix product label - 4014A40806070PK50-SIM
M8 x 60mm hex bolt marine grade 316 DIN 931 - partial thread DIN 931 hex bolt M8 x 60mm A4-70 A4 marine grade stainless steel, side profile Hexagon head detail - M8 x 60mm A4 stainless bolt, partial thread DIN 931 Simfix product label - 931A40806070PK10-SIM Simfix product label - 4014A40806070PK50-SIM

This M8 x 60mm hex bolt is manufactured to DIN 931 in A4 stainless steel (316 marine grade). DIN 931 specifies a part-threaded shank: the unthreaded plain section under the head spans the thickness of the joined parts, reducing stress concentration at the thread run-out and improving shear resistance compared with a fully threaded bolt. Property class A4-70 specifies a minimum tensile strength of 700 MPa - appropriate for structural connections and high-clamping-force applications. Pair with a matching M8 hex nut (DIN 934) or nyloc nut (DIN 985) for a complete through-bolted assembly.

Typical applications

  • Marine and coastal structures - jetties, pontoons, boat fixings
  • Swimming pool plant, water treatment facilities, and pump housings
  • Offshore and saltwater environments with prolonged wet exposure
  • Chemical plant, food processing, and washdown environments

Available in packs of 10 to 50, with free next-day UK delivery on orders over £50 and 30-day no-quibble returns.

Fastener styleHexagon head bolt, part threaded
StandardDIN 931
MaterialA4 stainless steel (316)
Property classA4-70
Thread sizeM8
Thread pitch1.25 mm (coarse)
Length60 mm
Head typeHex
Drive typeExternal hex (spanner)
Surface finishPlain (no plating)
HS commodity code7318157590
Recommended useMarine

RoHS and REACH compliant.
