M4 X 12 Six Lobe Button Flange 25 Pack ISO 7380-2 A4 Stainless Steel
- RRP
- £17.90
This M4 x 12mm socket button head flange screw is manufactured to ISO 7380-2 in A4 stainless steel (316 grade). ISO 7380-2 specifies a low domed head with an integral flange, driven by an internal hexagon socket, spreading the clamping load without a separate washer. The integral flange spreads the clamping force over a wider bearing area than the head alone, protecting softer materials and removing the need for a separate washer.
Typical applications
- Fixings into softer sheet, plastics, or thin panels
- Assemblies where a separate washer would be awkward to place
- Guards, covers, and enclosures
- Light structural and general engineering work
Available in packs of 25 to 200, with free next-day UK delivery on orders over £50 and 30-day no-quibble returns.
- RRP
- £17.90
This M4 x 12mm socket button head flange screw is manufactured to ISO 7380-2 in A4 stainless steel (316 grade). ISO 7380-2 specifies a low domed head with an integral flange, driven by an internal hexagon socket, spreading the clamping load without a separate washer. The integral flange spreads the clamping force over a wider bearing area than the head alone, protecting softer materials and removing the need for a separate washer.
Typical applications
- Fixings into softer sheet, plastics, or thin panels
- Assemblies where a separate washer would be awkward to place
- Guards, covers, and enclosures
- Light structural and general engineering work
Available in packs of 25 to 200, with free next-day UK delivery on orders over £50 and 30-day no-quibble returns.
-
files/simfix-2TBF5018_1.png
-
files/simfix-2TBF5018_2.png
-
files/simfix-2TBF5018_3.png
-
files/simfix-label-73802A404012T-D.png
-
files/simfix-label-73802A404012T-T.png
Complete the fixing
Matching nuts and washers in the same size, grade and thread as this screw.
M4 X 12 Six Lobe Button Flange ISO 7380-2 A4 Stainless Steel
Total for selected
This M4 x 12mm socket button head flange screw is manufactured to ISO 7380-2 in A4 stainless steel (316 grade). ISO 7380-2 specifies a low domed head with an integral flange, driven by an internal hexagon socket, spreading the clamping load without a separate washer. The integral flange spreads the clamping force over a wider bearing area than the head alone, protecting softer materials and removing the need for a separate washer.
Typical applications
- Fixings into softer sheet, plastics, or thin panels
- Assemblies where a separate washer would be awkward to place
- Guards, covers, and enclosures
- Light structural and general engineering work
Available in packs of 25 to 200, with free next-day UK delivery on orders over £50 and 30-day no-quibble returns.
*Photos, diagrams and other images are for illustration only and may not show the exact item supplied. Simfix reserves the right to alter or replace any photo, diagram or image at any time at its sole discretion.
**Orders that cannot be split will be rounded up to the next full pack or box quantity.
Simfix reserves the right to change quantities, stock levels and prices at any time. We accept no liability for the accuracy of dimensional data, DIN/ISO references, technical data, customs tariff codes or EAN barcodes.
| Fastener style | Flanged button head screw with six lobe drive |
|---|---|
| Standard | ISO 7380-2 |
| Material | A4 stainless steel (316) |
| Property class | A4 |
| Thread size | M4 |
| Thread pitch | 0.7 mm (coarse) |
| Length | 12 mm |
| Head type | Button Head |
| Drive type | Six lobe |
| Surface finish | Plain (no plating) |
| Recommended use | Marine |
RoHS and REACH compliant.
How do I choose between A2 and A4 stainless steel?
A2 (304) stainless steel suits most indoor, outdoor and workshop jobs. Choose A4 (316) marine grade for coastal, marine, poolside or other chloride-rich environments.
How do I make sure I order the right size?
Check the size in the product title and the standard, material and dimensions in the Product Specification tab. In M8 x 30, M8 is the thread diameter and 30 is the length in millimetres. See our size guide if you need more help.
