Simfix
M12 X 160 Hexagon Head Bolt 5 Pack DIN 931 A2 Stainless Steel
- RRP
- £6.05
This M12 x 160mm part threaded hex bolt is manufactured to DIN 931 in A2 stainless steel (304 grade). DIN 931 specifies a hex head bolt with a plain shank beneath the head and thread over the lower portion only, making it suited to joints that carry shear across the joint line. Property class A2-70 indicates a minimum tensile strength of 700 MPa - stronger than standard A2-50 and suited to structural fixings where higher clamping force is needed. The unthreaded shank sits in the bearing hole rather than the thread, locating the joint accurately and presenting a solid cross-section to shear loads instead of the reduced root diameter of a thread.
Typical applications
- Structural steel and heavy timber connections
- Pivot points, brackets, and load-bearing joints
- Machinery frames and equipment mounting
- Applications where the joint carries shear rather than tension
Available in packs of 5 to 25, with free next working day delivery on UK orders over £50 and 30-day returns. For coastal, marine, or chloride-rich environments, Simfix A4 (316 grade) equivalents are available.
- RRP
- £6.05
This M12 x 160mm part threaded hex bolt is manufactured to DIN 931 in A2 stainless steel (304 grade). DIN 931 specifies a hex head bolt with a plain shank beneath the head and thread over the lower portion only, making it suited to joints that carry shear across the joint line. Property class A2-70 indicates a minimum tensile strength of 700 MPa - stronger than standard A2-50 and suited to structural fixings where higher clamping force is needed. The unthreaded shank sits in the bearing hole rather than the thread, locating the joint accurately and presenting a solid cross-section to shear loads instead of the reduced root diameter of a thread.
Typical applications
- Structural steel and heavy timber connections
- Pivot points, brackets, and load-bearing joints
- Machinery frames and equipment mounting
- Applications where the joint carries shear rather than tension
Available in packs of 5 to 25, with free next working day delivery on UK orders over £50 and 30-day returns. For coastal, marine, or chloride-rich environments, Simfix A4 (316 grade) equivalents are available.
-
files/simfix-23108050_1.png
-
files/simfix-23108050_2.png
-
files/simfix-23108050_3.png
-
files/simfix-label-931A21216070-D.png
-
files/simfix-label-931A21216070-T.png
Complete the fixing
Matching nuts and washers in the same size, grade and thread as this bolt.
M12 X 160 Hexagon Head Bolt DIN 931 A2 Stainless Steel
Total for selected
This M12 x 160mm part threaded hex bolt is manufactured to DIN 931 in A2 stainless steel (304 grade). DIN 931 specifies a hex head bolt with a plain shank beneath the head and thread over the lower portion only, making it suited to joints that carry shear across the joint line. Property class A2-70 indicates a minimum tensile strength of 700 MPa - stronger than standard A2-50 and suited to structural fixings where higher clamping force is needed. The unthreaded shank sits in the bearing hole rather than the thread, locating the joint accurately and presenting a solid cross-section to shear loads instead of the reduced root diameter of a thread.
Typical applications
- Structural steel and heavy timber connections
- Pivot points, brackets, and load-bearing joints
- Machinery frames and equipment mounting
- Applications where the joint carries shear rather than tension
Available in packs of 5 to 25, with free next working day delivery on UK orders over £50 and 30-day returns. For coastal, marine, or chloride-rich environments, Simfix A4 (316 grade) equivalents are available.
*Photos, diagrams and other images are for illustration only and may not show the exact item supplied. Simfix reserves the right to alter or replace any photo, diagram or image at any time at its sole discretion.
**Orders that cannot be split will be rounded up to the next full pack or box quantity.
Simfix reserves the right to change quantities, stock levels and prices at any time. We accept no liability for the accuracy of dimensional data, DIN/ISO references, technical data, customs tariff codes or EAN barcodes.
| Fastener style | Hexagon head bolt, part threaded |
|---|---|
| Standard | DIN 931 |
| Material | A2 stainless steel (304) |
| Property class | A2-70 |
| Thread size | M12 |
| Thread pitch | 1.75 mm (coarse) |
| Length | 160 mm |
| Head type | Hexagon Head |
| Drive type | External hexagon |
| Surface finish | Plain (no plating) |
| Recommended use | Workshop |
RoHS and REACH compliant.
How do I choose between A2 and A4 stainless steel?
A2 (304) stainless steel suits most indoor, outdoor and workshop jobs. Choose A4 (316) marine grade for coastal, marine, poolside or other chloride-rich environments.
How do I make sure I order the right size?
Check the size in the product title and the standard, material and dimensions in the Product Specification tab. In M8 x 30, M8 is the thread diameter and 30 is the length in millimetres. See our size guide if you need more help.
When will my order arrive?
Orders placed before 3:30pm Monday-Friday are typically dispatched the same working day and every order is tracked. Next-day delivery is free over £50, or £5.50 below that threshold. Full options are shown at checkout.
What if I order the wrong item?
Email contact@simfix.com within 30 days of delivery with your order number. We will help arrange a refund or replacement. See our refunds information for the full process.
Is checkout secure?
Yes. Checkout is protected by SSL encryption and payments are processed through Shopify's secure checkout and supported payment providers. Simfix does not store your full card details.
-
