4.8 X 9.5 Six Lobe Pan Tapping Screw 25 Pack ISO 14585-C A2 Stainless Steel
- RRP
- £6.55
This 4.8 x 9.5mm six lobe pan head self-tapping screw is manufactured to ISO 14585-C in A2 stainless steel (304 grade). ISO 14585-C specifies a pan head self-tapping screw driven by a six lobe recess, forming its own thread with high torque transfer. The hardened thread cuts its own path into a pilot hole while the six lobe recess grips over a larger area than a cross recess, resisting cam-out under powered assembly.
Typical applications
- Powered assembly into sheet, board, and plastics
- Enclosure, ducting, and panel work
- Production lines where cam-out slows fitting
- Maintenance where fixings are removed repeatedly
Available in packs of 25 to 200, with free next working day delivery on UK orders over £50 and 30-day returns.
- RRP
- £6.55
This 4.8 x 9.5mm six lobe pan head self-tapping screw is manufactured to ISO 14585-C in A2 stainless steel (304 grade). ISO 14585-C specifies a pan head self-tapping screw driven by a six lobe recess, forming its own thread with high torque transfer. The hardened thread cuts its own path into a pilot hole while the six lobe recess grips over a larger area than a cross recess, resisting cam-out under powered assembly.
Typical applications
- Powered assembly into sheet, board, and plastics
- Enclosure, ducting, and panel work
- Production lines where cam-out slows fitting
- Maintenance where fixings are removed repeatedly
Available in packs of 25 to 200, with free next working day delivery on UK orders over £50 and 30-day returns.
-
files/simfix-281T4225_1.png
-
files/simfix-281T4225_2.png
-
files/simfix-281T4225_3.png
-
files/simfix-label-14585CA248009-D.png
-
files/simfix-label-14585CA248009-T.png
This 4.8 x 9.5mm six lobe pan head self-tapping screw is manufactured to ISO 14585-C in A2 stainless steel (304 grade). ISO 14585-C specifies a pan head self-tapping screw driven by a six lobe recess, forming its own thread with high torque transfer. The hardened thread cuts its own path into a pilot hole while the six lobe recess grips over a larger area than a cross recess, resisting cam-out under powered assembly.
Typical applications
- Powered assembly into sheet, board, and plastics
- Enclosure, ducting, and panel work
- Production lines where cam-out slows fitting
- Maintenance where fixings are removed repeatedly
Available in packs of 25 to 200, with free next working day delivery on UK orders over £50 and 30-day returns.
*Photos, diagrams and other images are for illustration only and may not show the exact item supplied. Simfix reserves the right to alter or replace any photo, diagram or image at any time at its sole discretion.
**Orders that cannot be split will be rounded up to the next full pack or box quantity.
Simfix reserves the right to change quantities, stock levels and prices at any time. We accept no liability for the accuracy of dimensional data, DIN/ISO references, technical data, customs tariff codes or EAN barcodes.
| Fastener style | Pan head self-tapping screw with six lobe drive |
|---|---|
| Standard | ISO 14585-C |
| Material | A2 stainless steel (304) |
| Property class | A2 |
| Thread size | M4.8 |
| Thread pitch | 1.6 mm |
| Head type | Pan Head |
| Drive type | Six lobe |
| Surface finish | Plain (no plating) |
| Recommended use | Indoor |
RoHS and REACH compliant.
How do I choose between A2 and A4 stainless steel?
A2 (304) stainless steel suits most indoor, outdoor and workshop jobs. Choose A4 (316) marine grade for coastal, marine, poolside or other chloride-rich environments.
How do I make sure I order the right size?
Check the size in the product title and the standard, material and dimensions in the Product Specification tab. In M8 x 30, M8 is the thread diameter and 30 is the length in millimetres. See our size guide if you need more help.
