Simfix

M30 Square Sect Spring Washer 25 Pack DIN 7980 Stainless Steel

SKU 7980A2305-D

In stock

RRP: £20.04

Diameter

Grade

Stainless steelA4 (316)

Pack size: Pack of 25 Pack of 200

Product variants

Quantity

Free next-day delivery over £50

Same-day shipping before 3:30pm

Secure SSL checkout

Speedy refunds

This M30 spring washer is manufactured to DIN 7980 in stainless steel. DIN 7980 specifies a split washer with a rectangular section and offset ends, for maintaining tension under vibration. The split ring is compressed flat under tightening and pushes back against the nut face, maintaining tension in the joint and helping resist loosening from vibration.

Typical applications

Joints subject to vibration and cyclic load
Machinery and equipment assembly
Vehicle and trailer fixings
General engineering where a nut must hold tension

Available in packs of 25 to 200, with free next-day UK delivery on orders over £50 and 30-day no-quibble returns.

RRP: £20.04

Typical applications

Joints subject to vibration and cyclic load
Machinery and equipment assembly
Vehicle and trailer fixings
General engineering where a nut must hold tension

Available in packs of 25 to 200, with free next-day UK delivery on orders over £50 and 30-day no-quibble returns.

files/simfix-2SS08_1.png
files/simfix-2SS08_2.png
files/simfix-label-7980A2305-D.png
files/simfix-label-7980A2305-T.png

Square section spring washer, stainless steel

Secure checkoutProtected, encrypted payment

Secure Checkout Certified Secure No Malware

Typical applications

Joints subject to vibration and cyclic load
Machinery and equipment assembly
Vehicle and trailer fixings
General engineering where a nut must hold tension

Available in packs of 25 to 200, with free next-day UK delivery on orders over £50 and 30-day no-quibble returns.

*Photos, diagrams and other images are for illustration only and may not show the exact item supplied. Simfix reserves the right to alter or replace any photo, diagram or image at any time at its sole discretion.

**Orders that cannot be split will be rounded up to the next full pack or box quantity.

Simfix reserves the right to change quantities, stock levels and prices at any time. We accept no liability for the accuracy of dimensional data, DIN/ISO references, technical data, customs tariff codes or EAN barcodes.

Fastener style	Square section spring washer
Standard	DIN 7980
Material	Stainless steel
Property class	EN 1.4310
Thread size	M30
Drive type	Square
Surface finish	Plain (no plating)
Recommended use	Workshop

RoHS and REACH compliant.

How do I choose between A2 and A4 stainless steel?

A2 (304) stainless steel suits most indoor, outdoor and workshop jobs. Choose A4 (316) marine grade for coastal, marine, poolside or other chloride-rich environments.

How do I make sure I order the right size?

Check the size in the product title and the standard, material and dimensions in the Product Specification tab. In M8 x 30, M8 is the thread diameter and 30 is the length in millimetres. See our size guide if you need more help.
