M30 X 140 Hexagon Head Bolt 1 Pack ISO 4014 A4-80 A4 Stainless Steel
- RRP
- £28.01
This M30 x 140mm part threaded hex bolt is manufactured to ISO 4014 in A4 stainless steel (316 grade). ISO 4014 specifies a hex head bolt with a plain shank beneath the head and thread over the lower portion only, making it suited to joints that carry shear across the joint line. Property class A4-80 indicates a minimum tensile strength of 800 MPa - stronger than standard A4-50 and suited to structural fixings where higher clamping force is needed. The unthreaded shank sits in the bearing hole rather than the thread, locating the joint accurately and presenting a solid cross-section to shear loads instead of the reduced root diameter of a thread.
Typical applications
- Structural steel and heavy timber connections
- Pivot points, brackets, and load-bearing joints
- Machinery frames and equipment mounting
- Applications where the joint carries shear rather than tension
Available singly and in packs of up to 5, with free next working day delivery on UK orders over £50 and 30-day returns.
- RRP
- £28.01
This M30 x 140mm part threaded hex bolt is manufactured to ISO 4014 in A4 stainless steel (316 grade). ISO 4014 specifies a hex head bolt with a plain shank beneath the head and thread over the lower portion only, making it suited to joints that carry shear across the joint line. Property class A4-80 indicates a minimum tensile strength of 800 MPa - stronger than standard A4-50 and suited to structural fixings where higher clamping force is needed. The unthreaded shank sits in the bearing hole rather than the thread, locating the joint accurately and presenting a solid cross-section to shear loads instead of the reduced root diameter of a thread.
Typical applications
- Structural steel and heavy timber connections
- Pivot points, brackets, and load-bearing joints
- Machinery frames and equipment mounting
- Applications where the joint carries shear rather than tension
Available singly and in packs of up to 5, with free next working day delivery on UK orders over £50 and 30-day returns.
-
files/simfix-23108050_1.png
-
files/simfix-23108050_2.png
-
files/simfix-23108050_3.png
-
files/simfix-label-4014A43014080-D.png
-
files/simfix-label-4014A43014080-T.png
Complete the fixing
Matching nuts and washers in the same size, grade and thread as this bolt.
M30 X 140 Hexagon Head Bolt ISO 4014 A4-80 A4 Stainless Steel
Total for selected
This M30 x 140mm part threaded hex bolt is manufactured to ISO 4014 in A4 stainless steel (316 grade). ISO 4014 specifies a hex head bolt with a plain shank beneath the head and thread over the lower portion only, making it suited to joints that carry shear across the joint line. Property class A4-80 indicates a minimum tensile strength of 800 MPa - stronger than standard A4-50 and suited to structural fixings where higher clamping force is needed. The unthreaded shank sits in the bearing hole rather than the thread, locating the joint accurately and presenting a solid cross-section to shear loads instead of the reduced root diameter of a thread.
Typical applications
- Structural steel and heavy timber connections
- Pivot points, brackets, and load-bearing joints
- Machinery frames and equipment mounting
- Applications where the joint carries shear rather than tension
Available singly and in packs of up to 5, with free next working day delivery on UK orders over £50 and 30-day returns.
*Photos, diagrams and other images are for illustration only and may not show the exact item supplied. Simfix reserves the right to alter or replace any photo, diagram or image at any time at its sole discretion.
**Orders that cannot be split will be rounded up to the next full pack or box quantity.
Simfix reserves the right to change quantities, stock levels and prices at any time. We accept no liability for the accuracy of dimensional data, DIN/ISO references, technical data, customs tariff codes or EAN barcodes.
| Fastener style | Hexagon head bolt, part threaded |
|---|---|
| Standard | ISO 4014 |
| Material | A4 stainless steel (316) |
| Property class | A4-80 |
| Thread size | M30 |
| Thread pitch | 3.5 mm (coarse) |
| Length | 140 mm |
| Head type | Hexagon Head |
| Drive type | External hexagon |
| Surface finish | Plain (no plating) |
| Recommended use | Marine |
RoHS and REACH compliant.
How do I choose between A2 and A4 stainless steel?
A2 (304) stainless steel suits most indoor, outdoor and workshop jobs. Choose A4 (316) marine grade for coastal, marine, poolside or other chloride-rich environments.
How do I make sure I order the right size?
Check the size in the product title and the standard, material and dimensions in the Product Specification tab. In M8 x 30, M8 is the thread diameter and 30 is the length in millimetres. See our size guide if you need more help.
