Simfix
M8 X 28 Hexagon Head Set Screw 10 Pack ISO 4017 A4 Stainless Steel
- RRP
- £6.65
This M8 x 28mm fully threaded hex bolt is manufactured to ISO 4017 in A4 stainless steel (316 grade). ISO 4017 specifies a hex head bolt with thread running the full length of the shank, making it suitable for nuts, threaded inserts, and through-bolted joints. Property class A4-80 indicates a minimum tensile strength of 800 MPa - stronger than standard A4-50 and suited to structural fixings where higher clamping force is needed. The full coarse thread runs the complete length of the shank, engaging all available thread in shallow tapped holes and maximising pull-out resistance.
Typical applications
- Light structural assemblies and general fabrication
- Joinery, cabinetry fixings, and furniture frames
- Mechanical brackets, shelving systems, and guard rails
- Machinery mounting and maintenance work
Available in packs of 10 to 50, with free next-day UK delivery on orders over £50 and 30-day no-quibble returns.
- RRP
- £6.65
This M8 x 28mm fully threaded hex bolt is manufactured to ISO 4017 in A4 stainless steel (316 grade). ISO 4017 specifies a hex head bolt with thread running the full length of the shank, making it suitable for nuts, threaded inserts, and through-bolted joints. Property class A4-80 indicates a minimum tensile strength of 800 MPa - stronger than standard A4-50 and suited to structural fixings where higher clamping force is needed. The full coarse thread runs the complete length of the shank, engaging all available thread in shallow tapped holes and maximising pull-out resistance.
Typical applications
- Light structural assemblies and general fabrication
- Joinery, cabinetry fixings, and furniture frames
- Mechanical brackets, shelving systems, and guard rails
- Machinery mounting and maintenance work
Available in packs of 10 to 50, with free next-day UK delivery on orders over £50 and 30-day no-quibble returns.
-
files/simfix-23308025_1.png
-
files/simfix-23308025_2.png
-
files/simfix-23308025_3.png
-
files/simfix-label-4017A40802880-D.png
-
files/simfix-label-4017A40802880-T.png
Complete the fixing
Matching nuts and washers in the same size, grade and thread as this screw.
M8 X 28 Hexagon Head Set Screw ISO 4017 A4 Stainless Steel
Total for selected
This M8 x 28mm fully threaded hex bolt is manufactured to ISO 4017 in A4 stainless steel (316 grade). ISO 4017 specifies a hex head bolt with thread running the full length of the shank, making it suitable for nuts, threaded inserts, and through-bolted joints. Property class A4-80 indicates a minimum tensile strength of 800 MPa - stronger than standard A4-50 and suited to structural fixings where higher clamping force is needed. The full coarse thread runs the complete length of the shank, engaging all available thread in shallow tapped holes and maximising pull-out resistance.
Typical applications
- Light structural assemblies and general fabrication
- Joinery, cabinetry fixings, and furniture frames
- Mechanical brackets, shelving systems, and guard rails
- Machinery mounting and maintenance work
Available in packs of 10 to 50, with free next-day UK delivery on orders over £50 and 30-day no-quibble returns.
*Photos, diagrams and other images are for illustration only and may not show the exact item supplied. Simfix reserves the right to alter or replace any photo, diagram or image at any time at its sole discretion.
**Orders that cannot be split will be rounded up to the next full pack or box quantity.
Simfix reserves the right to change quantities, stock levels and prices at any time. We accept no liability for the accuracy of dimensional data, DIN/ISO references, technical data, customs tariff codes or EAN barcodes.
| Fastener style | Hexagon head set screw, fully threaded |
|---|---|
| Standard | ISO 4017 |
| Material | A4 stainless steel (316) |
| Property class | A4-80 |
| Thread size | M8 |
| Thread pitch | 1.25 mm (coarse) |
| Length | 28 mm |
| Head type | Hexagon Head |
| Drive type | External hexagon |
| Surface finish | Plain (no plating) |
| Recommended use | Marine |
RoHS and REACH compliant.
How do I choose between A2 and A4 stainless steel?
A2 (304) stainless steel suits most indoor, outdoor and workshop jobs. Choose A4 (316) marine grade for coastal, marine, poolside or other chloride-rich environments.
How do I make sure I order the right size?
Check the size in the product title and the standard, material and dimensions in the Product Specification tab. In M8 x 30, M8 is the thread diameter and 30 is the length in millimetres. See our size guide if you need more help.
