Simfix
M8 X 55 Hex Non-Serrated Flange Screw 10 Pack DIN 6921 A2 Stainless Steel
- RRP
- £6.52
This M8 x 55mm hex flange screw is manufactured to DIN 6921 in A2 stainless steel (304 grade). DIN 6921 specifies a hex head screw with an integral flange beneath the head, spreading the clamping load without a separate washer. Property class A2-70 indicates a minimum tensile strength of 700 MPa - stronger than standard A2-50 and suited to structural fixings where higher clamping force is needed. The integral flange spreads clamping force over a wider bearing area than the head alone, protecting the surface and removing the need for a separate washer during assembly.
Typical applications
- Assembly work where a separate washer slows fitting
- Fixings into softer sheet, plastics, or castings
- Vehicle, trailer, and machinery assemblies
- Guards, brackets, and general fabrication
Available in packs of 10 to 50, with free next-day UK delivery on orders over £50 and 30-day no-quibble returns. For coastal, marine, or chloride-rich environments, Simfix A4 (316 grade) equivalents are available.
- RRP
- £6.52
This M8 x 55mm hex flange screw is manufactured to DIN 6921 in A2 stainless steel (304 grade). DIN 6921 specifies a hex head screw with an integral flange beneath the head, spreading the clamping load without a separate washer. Property class A2-70 indicates a minimum tensile strength of 700 MPa - stronger than standard A2-50 and suited to structural fixings where higher clamping force is needed. The integral flange spreads clamping force over a wider bearing area than the head alone, protecting the surface and removing the need for a separate washer during assembly.
Typical applications
- Assembly work where a separate washer slows fitting
- Fixings into softer sheet, plastics, or castings
- Vehicle, trailer, and machinery assemblies
- Guards, brackets, and general fabrication
Available in packs of 10 to 50, with free next-day UK delivery on orders over £50 and 30-day no-quibble returns. For coastal, marine, or chloride-rich environments, Simfix A4 (316 grade) equivalents are available.
-
files/simfix-2210830_1.png
-
files/simfix-2210830_2.png
-
files/simfix-2210830_3.png
-
files/simfix-label-6921A208055-D.png
-
files/simfix-label-6921A208055-T.png
Complete the fixing
Matching nuts and washers in the same size, grade and thread as this screw.
M8 X 55 Hex Non-Serrated Flange Screw DIN 6921 A2 Stainless Steel
Total for selected
This M8 x 55mm hex flange screw is manufactured to DIN 6921 in A2 stainless steel (304 grade). DIN 6921 specifies a hex head screw with an integral flange beneath the head, spreading the clamping load without a separate washer. Property class A2-70 indicates a minimum tensile strength of 700 MPa - stronger than standard A2-50 and suited to structural fixings where higher clamping force is needed. The integral flange spreads clamping force over a wider bearing area than the head alone, protecting the surface and removing the need for a separate washer during assembly.
Typical applications
- Assembly work where a separate washer slows fitting
- Fixings into softer sheet, plastics, or castings
- Vehicle, trailer, and machinery assemblies
- Guards, brackets, and general fabrication
Available in packs of 10 to 50, with free next-day UK delivery on orders over £50 and 30-day no-quibble returns. For coastal, marine, or chloride-rich environments, Simfix A4 (316 grade) equivalents are available.
*Photos, diagrams and other images are for illustration only and may not show the exact item supplied. Simfix reserves the right to alter or replace any photo, diagram or image at any time at its sole discretion.
**Orders that cannot be split will be rounded up to the next full pack or box quantity.
Simfix reserves the right to change quantities, stock levels and prices at any time. We accept no liability for the accuracy of dimensional data, DIN/ISO references, technical data, customs tariff codes or EAN barcodes.
| Fastener style | Hex head flange screw, non-serrated |
|---|---|
| Standard | DIN 6921 |
| Material | A2 stainless steel (304) |
| Property class | A2-70 |
| Thread size | M8 |
| Thread pitch | 1.25 mm (coarse) |
| Length | 55 mm |
| Head type | Hexagon Head with Flange |
| Drive type | External hexagon |
| Surface finish | Plain (no plating) |
| Recommended use | Workshop |
RoHS and REACH compliant.
How do I choose between A2 and A4 stainless steel?
A2 (304) stainless steel suits most indoor, outdoor and workshop jobs. Choose A4 (316) marine grade for coastal, marine, poolside or other chloride-rich environments.
How do I make sure I order the right size?
Check the size in the product title and the standard, material and dimensions in the Product Specification tab. In M8 x 30, M8 is the thread diameter and 30 is the length in millimetres. See our size guide if you need more help.
